Structural Steel Detailing

WE OFFER NUMEROUS STRUCTURAL DRAFTING AND STEEL DETAILING SERVICES, INCLUDING:

  • 3D modeling
  • 2D shop drawings
  • 2D erection drawings
  • Advanced bill of materials
  • Fabtrol-certified output
  • CNC, DXF, KISS, EJE
  • Foundation plans with footing and column schedules
  • Steel detailing such as fabrication drawings, erection drawings, field details, framing plans, anchor bolts with templates, embedded setting plans.
  • Materials reports such as advance bill of materials, pre-detailing, sequencing lists, cutting lists, assembly lists, members and parts lists, shop and field bolt lists, field bolt location lists, etc.
  • Materials reports such as advance bill of materials, pre-detailing, sequencing lists, cutting lists, assembly lists, members and parts lists, shop and field bolt lists, field bolt location lists, etc.Connections detailing such as beam-beam connections, beam-column connections, beam-slab connections, column-slab connections, diagonal brace connections, plan-brace connections, column-foundation connections, stairs, guardrails, platforms, catwalks, ladders, miscellaneous, etc.
  • Roof truss details.
  • Bill of materials for steel shop drawings.

WE SPECIALIZE IN STRUCTURAL DESIGN SUPPORT ACROSS THE FOLLOWING ASPECTS
  • Bridges
  • Hospitals
  • Schools and Universities
  • Stadiums
  • Theaters
  • Shopping Center
  • Churches

Miscellaneous Steel Detailing

Miscellaneous steel detailing demands a lot of self-decision while working on it, especially in modeling side. Also, this part of detailing demands good technical knowledge as well. Our well experienced team does each job precisely and through best method.

Estimation And Material Take-off

We have a quick estimation procedure that includes 3D modeling, Material Reports, Complexity study, Material take-off and Man Hour Consumption calculation. On customer's requirement, we can deliver material take off as well.
